VISION SATELLITE V8
Vision Satellite is the ideal solution to expand your facility’s dispensing capacity in an efficient and versatile way. Designed to function as a complementary module to the Vision V8 or Taos, which allows doubling the number of available selections while maintaining seamless and consistent integration. Its modular structure makes it easy to adapt to different configurations and needs, optimising space and the shopping experience without the need for lifting systems.
ANTI-VANDALISM PLATE CLOSURE
OPTIMIZATION, CAPACITY AND VOLUME
J-SUITE
MODULARITY WITH DIFFERENT SATELLITES
PRODUCT OUTPUT DETECTION PHOTOCELLS
EASY FLEX EXTRACTION SYSTEM
CONFIGURATION ACCORDING TO NEEDS
ENERGY-EFFICIENT LIGHTS
FEATURES
- Capacity up to 6 trays of up to 10 channels and 2 trays of up to 7 height-adjustable channels.
- Detection of correct sales by means of photocells.
- Continuous self-test of operation.
- Cooling unit on SATELLITE R290 V8 and SATELLITE REFRIG models. V8
- Operation in environments with 65% maximum humidity.
- Expiration date programming by selection number or channel. It inhibits the sale of these products.
- Flexible configuration. Easy to change the position of channels and partitions without tools.
- Intelligent or manual auto-adjustment of the push force for each channel, adapting to the characteristics of each product.
- Multi-sales system, capable of delivering several products in a single manoeuvre.
- FIFO system (First in First out), which ensures continuous product renewal.
DESIGN
Our Vision Satellite V8 machines, thanks to their adjustable channel system, have the advantage of adapting to any type of product. In addition, they have cutting-edge technology and an elegant and innovative design, resulting in a machine with high capacity and great product control.
- Elegant and robust design with four different finishes for the door (white, black, silver or Bluetec) and with the option of customization with corporate branding.
• Thermally insulated front safety glass with 16mm argon chamber of 1100×638 mm, which allows a wide view of the product and offers protection and great insulating capacity.
• LED lighting of the product in white color.
• Modular structure in furniture protected against corrosion and rust.
OPTIONS
- Assembly of different types of locks according to the customer’s needs.
- Polycarbonate protection installation for the front glass.
- It can incorporate a cooling group.
- Internal heater kit capable of keeping the products inside the machine up to 20°C above the ambient temperature. It prevents accidental freezing of products due to external environmental causes and tempers products that require it as long as they do not saturate the interior with moisture.
PROGRAMMING
- Machine control by means of a control module or a master machine connected through an RS485 communication port, both commanded by a JSD device, capable of simultaneously controlling four vending machines or three machines and four locker modules with a total of eighty compartments.
• In SATELLITE R290 V8 and REFRIG. V8, possibility of programming the interior temperature between 2ºC and 25ºC through the control machine or control module.
TELEMETRY
Our Jofemar electronic system J-LINK offers a wide range of functionalities to all our machines. One of them is the ability to use J-SUITE, our comprehensive and unified solution for machine management that allows you full control of the machine from anywhere in the world.
ADVANTAGES
- Compatibility with all Jofemar machines. You can use J-SUITE with all our products.
- Total stock control.
- Sending of technical and administrative alerts.
- Remote control of the machines from your computer, tablet, or mobile phone.
- Compatible with other payment systems.
- Option to have a closed-loop card reader.
- Compatible with non-Jofemar machines through standard protocols.
- Maximum data storage security.
- Automatic daily data backups.
- Full availability at any time.
- Access to sales statistics.
