VISION ESPLUS ECO
The Esplus eco V8 by Jofemar is our first next-generation vending machine, combining advanced technology with an elegant design. Its main difference from the EsPlus is its Class C energy efficiency, making it a more sustainable and cost effective option. Thanks to its large storage capacity, it offers a wide range of products that adapt to any environment. Additionally, it incorporates the innovative multi-sale function, allowing users to select multiple products in a single process, streamlining service and enhancing the shopping experience.
ANTI-VANDALISM PLATE CLOSURE
CAPACITY AND VOLUME OPTIMIZATION
J-SUITE
PRODUCT DELIVERY DETECTION PHOTOCELLS
EASY FLEX DELIVERY SYSTEM
ELEVATOR
FEATURES
- Capacity for up to 8 trays with up to 10 height-features channels.
- Percentage reduction in energy consumption: 24.13%.
- Ability to program the temperature and maintain an internal temperature from 4ºC to 25ºC.
- Operates in environments with up to 65% maximum humidity.
- Can hold a total of 100 kg of product.
- Correct sale detection through photocells.
- Continuous self-test operation. Expiration date programming by selection number or channel, inhibiting the sale of those products.
- Flexible configuration. Easy to change the position of channels and dividers without tools.
- Intelligent or manual self-adjustment of push force for each channel, adapting to the characteristics of each product.
- Large capacity elevator with the option of transparent areas (elevator and window) allowing the customer to have a better view of the product delivery cycle.
- Multi-sale system, capable of delivering multiple products in a single operation.
- FIFO (First In First Out) system.
DESIGN
Our ESPLUS V8 machines, thanks to their adjustable channel system, have the advantage of adapting to any type of product. Additionally, they feature cutting edge technology and an elegant, innovative design, resulting in a machine with high capacity and excellent product control.
- Elegant and robust design with four different finishes for the door (white, black, gray, or Bluetec) and the option for customization with corporate branding.
- LED lighting with selective on/off programming.
- Transparent front panel measuring 1,169 x 714 mm, allowing a wide view of our product.
- Modular structure in a cabinet protected against corrosion and rust.
- Large capacity elevator, with the option to be transparent (EsPlus TE) and with perimeter lighting.
OPTIONS
- EsPlus TE: illuminated transparent elevator and door with a window at the bottom. Perimeter lighting on the product exit door.
- EsPlus WE: illuminated transparent elevator and door without a window. Perimeter lighting on the product exit door.
- EsPlus standard: standard elevator and door without a window.
- Can incorporate a refrigeration unit.
- Installation of different types of locks according to customer needs.
- Internal heater kit capable of maintaining the products inside the machine up to 20°C above ambient temperature. This prevents accidental freezing of products due to external environmental causes and tempers products as needed, provided they do not saturate the interior with humidity.
PROGRAMMING
- Ability to program the machine’s internal temperature between 4ºC and 25ºC.
- Machine control via a control module or a master machine connected through an RS232 communication port, both commanded by a JSD device, capable of simultaneously controlling four vending machines or three machines and four locker modules with a total of eighty compartments.
- Collection and transmission of machine status data to the JSD control device to inhibit the sale of spoiled products.
TELEMETRY
Our Jofemar electronic system J-LINK offers a wide range of functionalities to all our machines. One of them is the ability to use J-SUITE, our comprehensive and unified solution for machine management that allows you full control of the machine from anywhere in the world.
ADVANTAGES
- Compatibility with all Jofemar machines. You can use J-SUITE with all our products.
- Total stock control.
- Sending of technical and administrative alerts.
- Remote control of the machines from your computer, tablet, or mobile phone.
- Compatible with other payment systems.
- Option to have a closed-loop card reader.
- Compatible with non-Jofemar machines through standard protocols.
- Maximum data storage security.
- Automatic daily data backups.
- Full availability at any time.
- Access to sales statistics.
