COFFEEMAR XL 46
The Coffeemar XL 46 model has been specially designed to offer a large takeaway coffee, and to enable the dispensing of two types of coffee in the same machine. Applying the technology developed by Jofemar for its Coffeemar machine range, which allows all the quality of the coffee beans to be extracted, and includes the best presentations for a vending machine.
PRESSURE VALVE IN THE DISTRIBUTION UNIT
ANTI-VANDALISM PLATE CLOSURE
J-SUITE
MONITORED WATER DISTRIBUTOR, NO SOLENOID VALVES
CUSTOMIZED SETUP TO SUIT YOUR REQUIREMENTS
CAPACITIVE KEYBOARD
PAYMENT SYSTEMS WITH WALLET AND CARD HOLDER
FINGERPRINT-RESISTANT STAINLESS STEEL
FEATURES
- Pressure valve in group of delivery to maintain constant pressure throughout the delivery cycle.
- Motorized water distributor without solenoid valves.
- Aluminium boiler with resistance and encapsulated probes, without contact with water (avoiding O-rings and limescale creation).
- Extractor for glasses up to 80mm in diameter and 117 mm high, 350 ml.
- Delivery of lids for the glass, with the possibility of pre-selection of these and surcharge in price.
- Adjustable brush dispenser between 75 mm and 115 mm long.
- Mixing circuit self-washing, product output: manual or automatic (programmable).
- System for adding anti-steam sugar directly to the glass.
- Constant temperature control in the water boiler.
- Braking at the exit gate.
- Easy cleaning and maintenance of removable elements.
- Express delivery speed (programmable).
- Double dispensing group with the option of simultaneous operation with the same type of coffee, the option of two different types of coffee or the option of coffee and tea on a leaf.
DESING
Our Coffeemar XL46 machine has a perfect combination of innovation and modern aesthetics. Its double dispen-sing group, two coffee tanks and double water circuit stand out, which combined allow you to offer a coffee of up to 16 gr, dispensed in up to 350ml of water, in less than 30 seconds.
- Furniture in steel treated against corrosion and anti-vandal closure with integrated door in the cabin.
- Front in tempered glass embedded in metal, without access to the side edges and capacitive keyboard in the Bluetec option.
- Capacitive keyboard in the Bluetec option and membrane keyboard in the Coffeemar XL 46 option.
- Independent recovery key, backlit.
- Product collection drawer illuminated with white LED and with the option to be controlled.
OPTIONS
- Extractor for glasses up to 80mm in diameter and 117mm high, 350ml.
- Self-contained water kit (one or two tanks of 25 l each).
- Water filters: water softener or flavor filter.
- Delivery of lids for the glass, with the possibility of pre-selection of these and surcharge on the price.
- Possibility of having 2 containers of grain + 6 of soluble + the con-tainer of sugar.
- Palette dispenser.
PROGRAMMING
- Option to extract data with J-SUITE via J-LINK.
- It incorporates a display module where product information can be displayed.
- DEX connector as the only solution for accounting and telemetry extraction.
- Programming button to access the different menus of the machine.
- Interactive adjustment of programming options using the machine’s own graphic display.
TELEMETRY
Our Jofemar electronic system J-LINK offers a wide range of functionalities to all our machines. One of them is the ability to use J-SUITE, our comprehensive and unified solution for machine management that allows you full control of the machine from anywhere in the world.
ADVANTAGES
- Compatibility across all Jofemar machines; you can use J-SUITE on all our products.
- Total stock control.
- Remote machine control from your computer, tablet, or mobile device.
- Compatible with other payment systems.
- Option to have a closed circuit card reader.
- Compatible with non-Jofemar machines through standard protocols.
- Control of product weight, cups and pallets.
- Control of product weight, cups and pallets.
- Control of product compositions.
